Stainless Steel Angle/Sections
316 Stainless Steel Angle/Sections/U Channel
316 Stainless Steel Angle/Sections/U Channel
316 stainless steel U-channel is an austenitic chromium-nickel stainless steel reinforced with molybdenum, which enhances its resistance to corrosion, especially in chloride environments. This U-channel is known for superior corrosion resistance, making it ideal for marine and chemical applications. It offers excellent weldability and formability, and is commonly used in environments where both strength and resistance to corrosion are required, such as in architectural trims, construction frameworks, and marine structures. 316 stainless steel U-channel is also used in food processing, pharmaceutical equipment, and medical device manufacturing due to its excellent durability and resistance to a wide range of chemicals and acids.

Email：tgyl@tisco-ssplate.com

Send Now
BASIC PARAMETERS
PRODUCT MATERIAL
NameStainless Steel Angle/Sections/Flat
TechniqueCR/HR
StandardAISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc.
Steel Grade

201;301;304;310S;316;321;430;2205;2507;904,etc.

Tolerance+/-0.01-1.0%
LengthCustomization
Thickness0.4-30mm or customized
ServiceOEM, customized processing service
Processing TypeCutting,Bending,Stamping,elding,Machining,Forging
GradeCSiMnpSNiCrMoN
201≤0 .15≤0.8≤1.0≤0.04≤ 0.0317.5-18.519.5-20.56.0-6.50.18-0.20
904L≤0 .02≤1.0≤2.0≤0.045≤0.03523.0-28.019.0-23.04.0-5.0≤0.1
654SMO≤0 .02≤0 .52.0-4.0≤0.03≤0.00521.0-23.024.0-25.07.0-8.00.45-0.55
253MA0.05-0.11.4-2.0-≤0.045≤ 0.0310.0-12.020.0-22.0-0.14-0.20
AL-6XN≤0 .02≤1.0≤2.0≤0.04≤ 0.0123.5-25.520.0-22.06.0-7.00.18-0.25
304≤0 .08≤1.0≤2.0≤0.045≤ 0.038.0-10.518.0-20.0--
304L≤0.03≤1.0≤2.0≤0.035≤ 0.039.0-13.018.0-20.0--
309S≤0.08≤1.0≤2.0≤0.045≤ 0.0312.0-15.022.0-24.0--
310S≤0.08≤1.5≤2.0≤0.035≤ 0.0319.0-22.024.0-26.0--
316≤0.08≤1.0≤2.0≤0.045≤ 0.0310.0-14.016.0-18.02.0-3.0-
316L≤0 .03≤1.0≤2.0≤0.045≤ 0.0312.0-15.016.0 -18.02.0 -3.0-
S32760≤ 0 .03≤1.0≤1.0≤0.035≤ 0.0156.0-8.024.0 -26.03.0-4.00.2-0.3
S32750≤ 0 .03≤0.8≤1.2≤0.035≤0.026.0-8.024.0-26.02.0-3.00.24-0.32

Quick Links

Packaging Shipping

Packing: seaworthy wooden pallets,water proof paper,pvc film,interleaving paper, in 20' or 40' container or as per customers' requirements.
-- 20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)
-- 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)
-- 40ft HC:12032mm(Lengh)x2352mm(Width)x2698mm(High)

FAQ

Q1 : How do you control quality ?

A1 : Mill Test Certification is supplied with shipment, Third Party Inspection is available. and we also get ISO,SGS,Alibaba Verified.



Q2 : How many coutries you already exported ?
A2 : Exported to more than 50 countries mainly from America, Russia, UK, Kuwait, Egypt, Turkey, Jordan,India, etc.



Q3 : What are the advantages of your company ?
A3 : We have many professionals, technical personnel, more competitive prices and best after-dales service.



Q4: Can you provide sample ?
A4: We can provide the samll samples in stock for free, as long as you contact us.Customized samples will take about 5-7days.
