Aluminum Coil/Strip/Foil
6063 Aluminum Coil/Strip/Foil

‹

›

‹

  • 6063 Aluminum Coil/Strip/Foil
  • 6063 Aluminum Coil/Strip/Foil
  • 6063 Aluminum Coil/Strip/Foil
  • 6063 Aluminum Coil/Strip/Foil

›

6063 Aluminum Coil, Strip, and Foil are heat-treatable magnesium-silicon alloys highly regarded for their extraordinary surface quality and excellent response to anodizing. While slightly lower in strength than 6061, 6063 provides a much smoother finish and superior formability, making it the premier "architectural grade" choice for thin-gauge applications.

Email：sales1@tisco-ssplate.com

Send Now

Description

 Applications

Architecture & DecorElectronics & ITElectrical PowerAutomotive TrimConsumer Goods
Solar & EnergyHVAC & ThermalSignage & DisplaysFurnitureMedical Housing


Specifications Table

Product Name6063 Aluminum Coil / Strip / Foil
ThicknessStrip/Coil: 0.2 mm - 6.0 mm
Width10 mm - 2600 mm (Slit widths available upon request)
Coil Inner Diameter (ID)150 mm, 300 mm, 400 mm, 505 mm (Customizable)
TempersO, T4, T5, T6, F
Surface FinishMill finish, Color Coated (PE/PVDF), Anodized, Wood Grain
ProtectionInterleaved paper, clear PE/PVC protective film (upon request)

Standard Approximate Comparison Table

Region / StandardGB (China)ASTM (USA)EN (Europe)JIS (Japan)ISO (International)
Equivalent Grade60636063EN AW-6063 / AlMg0.7SiA6063AlMg0.7Si

Chemical Composition Table (%)

AlMgSiFe (Max)Cu (Max)Mn (Max)Cr (Max)Zn (Max)Ti (Max)Other (Each)Other (Total)
Remainder0.45 - 0.90.20 - 0.600.350.100.100.100.100.100.050.15


Mechanical Properties Table

TemperTensile Strength, Rm (MPa)Yield Strength, Rp0.2 (MPa)Elongation, A50mm (%)
O≤ 130≤ 65≥ 14
T4≥ 130≥ 70≥ 14
T5≥ 160≥ 110≥ 8
T6≥ 205≥ 170≥ 8


Physical Properties Table

Density (g/cm³)Melting Point (°C)Thermal Conductivity (W/m·K)Electrical Conductivity (%IACS)Modulus of Elasticity (GPa)
2.69615 - 6552005369


Quick Links

Packaging Shipping

Packing: seaworthy wooden pallets,water proof paper,pvc film,interleaving paper, in 20' or 40' container or as per customers' requirements.
-- 20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)
-- 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)
-- 40ft HC:12032mm(Lengh)x2352mm(Width)x2698mm(High)

Application

Our products are used in a wide range of applications and various industries.Below are a few of them:

Gas Processing Industries
Petrochemical Industries
Power Generation Industries
Food Processing Industries
Chemical Industries
Oil & Gas Industries
Fertilizers Industries
Sugar Industries

FAQ

Q1 : How do you control quality ?

A1 : Mill Test Certification is supplied with shipment, Third Party Inspection is available. and we also get ISO,SGS,Alibaba Verified.



Q2 : How many coutries you already exported ?
A2 : Exported to more than 50 countries mainly from America, Russia, UK, Kuwait, Egypt, Turkey, Jordan,India, etc.



Q3 : What are the advantages of your company ?
A3 : We have many professionals, technical personnel, more competitive prices and best after-dales service.



Q4: Can you provide sample ?
A4: We can provide the samll samples in stock for free, as long as you contact us.Customized samples will take about 5-7days.
