Aluminum Plate/Sheet
1050 Aluminum Plate/Sheet

‹

›

‹

  • 1050 Aluminum Plate/Sheet
  • 1050 Aluminum Plate/Sheet
  • 1050 Aluminum Plate/Sheet
  • 1050 Aluminum Plate/Sheet

›

1050 Aluminum Plate/Sheet is a high-purity aluminum product (99.50% minimum Al content) known for its excellent electrical and thermal conductivity, high ductility, and superior corrosion resistance. As a non-heat-treatable alloy, it offers outstanding workability and weldability, making it ideal for applications requiring severe forming or specialized finishing like anodizing. It is widely used in the production of chemical equipment, electrical conductors, heat sinks, lighting reflectors, and food industry containers, where its high purity ensures both safety and performance.

Email：sales1@tisco-ssplate.com

Send Now

Description

Applications

Chemical & Food ProcessElectrical & ElectronicsLighting & ReflectorsSignage & AdvertisingArchitecture
Automotive (Decorative)PackagingHousehold AppliancesHVAC & Heat ExchangersGeneral Fabrication


Product Specification

Product Name1050 Aluminum Plate / Sheet
Series1000 Series (Pure Aluminum)
TemperO, H12, H14, H16, H18, H24, etc.
Thickness

0.2mm - 100mm (Customizable

)

Width

100mm - 2600m

m

Length500mm - 10000mm or Coil
StandardGB/T 3880, ASTM B209, EN 485
Surface FinishMill Finish, Bright, Polished, Brushed, Embossed, Color Coated
Scope of ApplicationChemical industry equipment, food industry containers, architectural flashings, lamp reflectors, cable sheathing, and signage.
CertificateISO, SGS, BV, REACH, RoHS
Production TechnologyHot Rolled (DC) / Cold Rolled (CC)
Edge ProcessingMill Edge, Slit Edge

Approximate Standard

Standard SystemUNSISO (Global)EN (Europe)JIS (Japan)GB/T (China)
Grade (Approx.)A91050Al 99.5AW-1050AA10501050


Chemical Composition (wt%)

ElementAl (Aluminum)Fe (Iron)Si (Silicon)Cu (Copper)Mn (Manganese)Mg (Magnesium)Zn (Zinc)Ti (Titanium)
Composition ≥99.50≤0.40 ≥0.25 ≤0.05 ≤0.05≤0.05≤0.07≤0.05


Mechanical Properties (H14 Temper)

PropertyMetric (MPa)Imperial (ksi)
Tensile Strength (Rm)105 - 14515 - 21
Yield Strength (Rp0.2)≥85≥12
Elongation (A50mm)≥6% ≥6%
Hardness (HB)~30 - 35~30 - 35


Physical Properties

PropertyValueUnits
Density2.70g/cm³
Melting Point~640 - 655℃
Modulus of Elasticity71Gpa
Thermal Conductivity222W/m.K
Electrical Conductivity35

MS/m

（60%IACS）


Quick Links

Packaging Shipping

Packing: seaworthy wooden pallets,water proof paper,pvc film,interleaving paper, in 20' or 40' container or as per customers' requirements.
-- 20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)
-- 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)
-- 40ft HC:12032mm(Lengh)x2352mm(Width)x2698mm(High)

Application

Our products are used in a wide range of applications and various industries.Below are a few of them:

Gas Processing Industries
Petrochemical Industries
Power Generation Industries
Food Processing Industries
Chemical Industries
Oil & Gas Industries
Fertilizers Industries
Sugar Industries

FAQ

Q1 : How do you control quality ?

A1 : Mill Test Certification is supplied with shipment, Third Party Inspection is available. and we also get ISO,SGS,Alibaba Verified.



Q2 : How many coutries you already exported ?
A2 : Exported to more than 50 countries mainly from America, Russia, UK, Kuwait, Egypt, Turkey, Jordan,India, etc.



Q3 : What are the advantages of your company ?
A3 : We have many professionals, technical personnel, more competitive prices and best after-dales service.



Q4: Can you provide sample ?
A4: We can provide the samll samples in stock for free, as long as you contact us.Customized samples will take about 5-7days.
