Aluminum Pipe/Tube
3003 Aluminum Pipe/Tube

‹

›

‹

  • 3003 Aluminum Pipe/Tube
  • 3003 Aluminum Pipe/Tube
  • 3003 Aluminum Pipe/Tube
  • 3003 Aluminum Pipe/Tube

›

3003 Aluminum Pipe/Tube is a widely used manganese-alloyed aluminum product known for its excellent atmospheric corrosion resistance and moderate strength. It is approximately 20% stronger than 1100 series aluminum, making it a robust choice for general-purpose applications that require durability without the weight of steel.

Email：sales1@tisco-ssplate.com

Send Now

Description

Applications

HVAC & RefrigerationAutomotive & TransportChemical ProcessingPower & EnergyConstruction
Kitchenware & FoodMedical EquipmentAgricultural IrrigationFuel & Gas SystemsGeneral Fabrication


Specifications Table


FeatureDetails
Product Name3003 Aluminum Pipe / Tube
ShapeRound, Square, Rectangular, Custom Extruded Profiles
Outer Diameter (OD)3 mm - 500 mm (Custom sizes available)
Wall Thickness (WT)0.5 mm - 50 mm
Length1000 mm - 12000 mm (Standard: 3000mm, 5800mm, 6000mm)
TempersO, H14, H18, H112, F
Processing MethodExtruded, Seamless, Drawn
Surface FinishMill finish, Anodized, Polished, Brushed


Standard Approximate Comparison Table

Region / StandardGB (China)ASTM (USA)EN (Europe)JIS (Japan)ISO (International)
Equivalent Grade30033003EN AW-3003 / AlMn1CuA3003AlMn1Cu


Chemical Composition Table (%)

AlSi (Max)Fe (Max)CuMnZn (Max)Other (Each)Other (Total)
Remainder0.600.700.05 - 0.201.0 - 1.50.100.050.15


Mechanical Properties Table

TemperTensile Strength, Rm (MPa)Yield Strength, Rp0.2 (MPa)Elongation, A50mm (%)
O95 - 130≥ 35≥ 25
H14140 - 180≥ 115≥ 8
H18≥ 185≥ 165≥ 4
H11295 - 130≥ 35≥ 20


Physical Properties Table

Density (g/cm³)Melting Point (°C)Thermal Conductivity (W/m·K)Electrical Conductivity (%IACS)Modulus of Elasticity (GPa)
2.73643 - 6541934170


Quick Links

Packaging Shipping

Packing: seaworthy wooden pallets,water proof paper,pvc film,interleaving paper, in 20' or 40' container or as per customers' requirements.
-- 20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)
-- 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)
-- 40ft HC:12032mm(Lengh)x2352mm(Width)x2698mm(High)

Application

Our products are used in a wide range of applications and various industries.Below are a few of them:

Gas Processing Industries
Petrochemical Industries
Power Generation Industries
Food Processing Industries
Chemical Industries
Oil & Gas Industries
Fertilizers Industries
Sugar Industries
