Copper rod
C26000 Brass Rod

‹

›

‹

  • C26000 Brass Rod
  • C26000 Brass Rod
  • C26000 Brass Rod
  • C26000 Brass Rod
  • C26000 Brass Rod

›

C26000 brass rod, widely known as Cartridge Brass or 70/30 Brass, is a high-performance alpha brass. With a composition of 70% copper and 30% zinc, it offers the best combination of strength and ductility among the yellow brasses. While famous for its role in ammunition, in rod form, it is highly valued for components that require severe cold-working, flaring, or specialized machining.

Email：sales1@tisco-ssplate.com

Send Now

Description

Applications

AmmunitionAutomotiveMusical InstrumentsElectronicsArchitecture
PlumbingAppliance Mfg.Fastener Mfg.HardwareIndustrial Mach.


Specifications Table

Product NameC26000 Cartridge Brass Rod / Bar
StandardASTM B134, ASTM B135, EN 12163, JIS C2600
ShapeRound, Hexagonal, Square, Flat
Diameter Range2 mm - 180 mm
Length2m - 6m (Standard), or cut-to-length
Toleranceh8, h9, h11 (Cold Drawn)
Temper (Hardness)Soft/Annealed (O60), 1/2 Hard (H02), Hard (H04)
Surface FinishBright, Polished, Pickled

Standard Grade Comparison Table

Region / StandardUNS (USA)EN/DIN (Europe)JIS (Japan)GB (China)
Equivalent GradeC26000CW505L / CuZn30C2600H70


Chemical Composition Table (%)

ElementCopper (Cu)Zinc (Zn)Iron (Fe) (Max)Lead (Pb) (Max)
Range68.5 - 71.5Remainder0.050.07


Mechanical Properties Table (Typical for H02 Half-Hard)

PropertyPerformance Data
Tensile Strength (Rm)370 - 460 MPa
Yield Strength (Rp0.2)250 - 380 MPa
Elongation (A50mm)≥20%
Hardness (Rockwell B)55 - 75 HRB


Quick Links

Packaging Shipping

Packing: seaworthy wooden pallets,water proof paper,pvc film,interleaving paper, in 20' or 40' container or as per customers' requirements.
-- 20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)
-- 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)
-- 40ft HC:12032mm(Lengh)x2352mm(Width)x2698mm(High)

Application

Our products are used in a wide range of applications and various industries.Below are a few of them:

Gas Processing Industries
Petrochemical Industries
Power Generation Industries
Food Processing Industries
Chemical Industries
Oil & Gas Industries
Fertilizers Industries
Sugar Industries

FAQ

Q1 : How do you control quality ?

A1 : Mill Test Certification is supplied with shipment, Third Party Inspection is available. and we also get ISO,SGS,Alibaba Verified.



Q2 : How many coutries you already exported ?
A2 : Exported to more than 50 countries mainly from America, Russia, UK, Kuwait, Egypt, Turkey, Jordan,India, etc.



Q3 : What are the advantages of your company ?
A3 : We have many professionals, technical personnel, more competitive prices and best after-dales service.



Q4: Can you provide sample ?
A4: We can provide the samll samples in stock for free, as long as you contact us.Customized samples will take about 5-7days.
